Description

Clear as Heaven, Loud as Hell
Featuring a custom designed 6.5 2-way coaxial driver from legendary loudspeaker company Tannoy, VoiceSolo FX150 delivers exceptional musical clarity and a premium full range punch.
Not only is the tone kept intact and pristine, but the expert voicing of the driver means that more volume and power is drawn from the 150 Watts than any other system in the same class. In other words, even when it gets loud on stage, youll hear yourselfand your musicprojected perfectly.

Controls
• Front panel
• Encoder with light ring for mix controls
• Master Volume Control
• Channel 1 and 2 (Level, Adaptice Vocal Tone on/off, 3 band EQ, Reverb send)
• Aux Channel (Level, Voice Cancel, 3 band EQ)
• 9 Reverb types
• Rear Panel
• Hi-Z enable (Channel 1)
• Output select: Full mix/Channel 1 Processed
• Phantom power on/off

Size

• Height: 8.25 inches (210 mm)
• Width: 11.25 inches (286 mm)
• Depth: 7.25 inches (184 mm)

Weight

• Weight: 6.75 lbs (3 kg)

Construction

• Rigid, very low resonance high impact polystyrene
• One-click Easy Grip mic-stand mounting system

Analog Inputs

• XLR/TRS Combo Jacks (channel 1 and 2)
• 1/8 Stereo Aux Input

Analog Outputs

• XLR true stage monitor pass thru (channel 2)
• XLR processed mix output

Loudspeaker

• Full Range 6.5 Tannoy 2-way coaxial ICT Driver

Amplifier

• 150W Class-D
• Smart Power compensation and protection

Power

• Power supply (supplied) 42.5V, 1.5A

Safety

• EMCComplies with EN 55103-1 and EN 55103-2 FCC part 15, Class B, CISPR 22, Class B
• Safetycertified to IEC 65, EN 60065, UL6500 and CSA IEC 65, EN 60065, UL6500 and CSA

Included with VoiceSolo FX150

• Region specific power supply
• Adaptor for stand-alone position
• User guide
